TP-Link AX6600 Tri-Band Wi-Fi Gaming Router Archer GX90

Beast features of TP-Link AX6600 Archer GX90

Game Band – Tri-Band structure provides a 4.8 Gbps Game Band exclusive for your gaming rigs and brings pure immersion.^† ^‡
Game Accelerator – Detect and optimize gaming streams, to ensure your gaming stays immersive.
The Statistics – Real-time latency, game duration and network resource allocation in a glance with fine-tuned UI.
Game Protector – Keep your accounts and documents safe with Homecare™ security system.
Expansive Coverage – 8 antennas, Beamforming, high-power FEM, 4T4R combine to deliver WiFi coverage up to a 4-bedroom house.
2.5 Gbps Wired Connection – Unleash the potential of your next-level bandwidth network with a 2.5 Gbps WAN/LAN port.
Powerful Processing – 1.5 GHz Quad-Core CPU ensure your network performance always at peak run.
Easy Setup – Set it up in minutes with the powerful Tether app.

PURE GAMING PURE IMMERSION

AX6600 Tri-Band Wi-Fi 6 Gaming Router

Archer GX90

GX90

Wi-Fi 6
Gaming Band

Low Latency

Game Accelerator

Playing Statistics

Game Protector

Whole Home One Mesh WiFi

FUELS YOUR WINNING WITH POWERFUL TRI-BAND

Archer GX90 provides 3 distinct bands with combined speed up to warp 6579 Mbps. A fully featured Gaming Band is equiped with 4T4R and HE160 technology, offering all your gaming rigs at top speed 4804 Mbps and preventing interference from other devices.^†‡

GX90

LIGHTNING ATTACK TO DEFEAT LATENCY

More connected devices mean more fun, without dragging down performance. Revolutionary OFDMA is introduced to improve average throughput by 4× and cut the latency. Take advantage of incredibly low latency to demolish your enemies, with your team crew together.^**

GX90

CRUSH THE LAG WIN THE GAME

GAME ACCELERATOR automatically detects and optimizes gaming streams, to ensure your gaming stays immersive, and keep your network as fast as your reaction speed.^△

GX90

KNOW YOUR NETWORK

GAME STATISTICS shows the real-time latency, game duration and system utilization at a glance in a refreshed dashboard with fine-tuned UI elements, puts total control at your fingertips.

GX90

KEEP ALL ELEMENTS SECURITY

GAME PROTECTOR keeps your accounts and system safe. This enhanced HomeCare™ security system provides malicious site checker, portintrusion prevention, and infected device isolation, delivering comprehensive antivirus protection that ensures you’re total security while gaming online.

TP-Link AX6600 Archer GX90

GAME ON THE FAST LANE

GAMING BAND—a dedicated gaming band for your game rigs, makes your online games and your families’ Netflix 4K streaming no more competitor.
DFS expands available channel automatically, get on the more vacant lane and boost the game.

TP-Link AX6600 Archer GX90

BATTLE-TESTED HARDWARE

Equipped with 1.5 GHz Quad-Core CPU to handle huge throughput and crush the lag. 2.5 Gbps WAN/LAN port and two USB ports provide versatile connectivity to your home network.

TP-Link AX6600 Archer GX90

Specification

WIRELESS
Standards	Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz
WiFi Speeds	AX6600 5 GHz: 4804 Mbps (802.11ax, HE160) 5 GHz: 1201 Mbps (802.11ax) 2.4 GHz: 574 Mbps (802.11ax)
WiFi Range	4 Bedroom Houses 8× Detachable High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range High-Power FEM Improves transmission power to strengthen signal coverage 4T4R Multiple streams in the same band strengthen the fault tolerance in transmission
WiFi Capacity	Very High Tri-Band Allocate devices to different bands for optimal performance 4×4 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple Wi-Fi 6 clients Airtime Fairness Improves network efficiency by limiting excessive occupation DFS Access an extra band to reduce congestion 8 Streams Connect your devices to more bandwidth
Working Modes	Router Mode Access Point Mode

HARDWARE
Processor	1.5 GHz Quad-Core CPU
Ethernet Ports	1× 2.5 Gbps WAN/LAN Port 1× Gigabit WAN/LAN Port 3× Gigabit LAN Ports
USB Support	1× USB 3.0 Port 1× USB 2.0 PortSupported Partition Formats: NTFS, exFAT, HFS+, FAT32Supported Functions: Apple Time Machine FTP Server Media Server Samba Server
Buttons	Wi-Fi On/Off Button Power On/Off Button LED On/Off Button WPS Button Reset Button
Power	12 V ⎓ 5 A

SECURITY
WiFi Encryption	WPA WPA2 WPA3 WPA/WPA2-Enterprise (802.1x)
Network Security	SPI Firewall Access Control IP & MAC Binding Application Layer GatewayHomeCare™ Antivirus Malicious Site Checker Port Intrusion Prevention Infected Device Isolation Notification and Log
Guest Network	2× 5 GHz Guest Network 1× 2.4 GHz Guest Network
VPN Server	OpenVPN PPTP

SOFTWARE
Protocols	IPv4 IPv6
Game Center	1.Game Accelerator Detects and optimizes gaming streams to keep latency as low as possible 2.Game Statistics Check real-time latency, system utilization, and game duration on a redesigned dashboard to tweak every detail 3.Game Protector Keep your accounts and system safe with HomeCare™ antivirus protection
Service Kits	HomeCare™
OneMesh™	OneMesh™ Supported Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Parental Controls	HomeCare™ Parental Controls Custom Profiles Content Filtering App Block URL Filtering Time Limit Time Schedule (Bedtime) Log Insight
WAN Types	Dynamic IP Static IP PPPoE PPTP L2TP
Quality of Service	Game Accelerator QoS. QoS by Device HomeCare™ QoS QoS by Application
Cloud Service	Auto Firmware Upgrade OTA Firmware Upgrade TP-Link ID DDNS
NAT Forwarding	Port Forwarding Port Triggering DMZ UPnP
IPTV	IGMP Proxy IGMP Snooping Bridge Tag VLAN
DHCP	Address Reservation DHCP Client List Server
DDNS	TP-Link NO-IP DynDNS
Management	Tether App Webpage

OTHER

System Requirements

Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)

Certifications

FCC, CE, RoHS

Environment

Operating Temperature: 0℃~40℃ (32℉ ~104℉)

Storage Temperature: -40℃~70℃ (-40℉ ~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

TEST DATA

WiFi Transmission Power

CE:
<20dBm(2.4GHz)
<23dBm(5.15GHz~5.35GHz)
<30dBm(5.47GHz~5.725GHz)
FCC:
<30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz)
<24dBm(5.25GHz-5.35GHz & 5.47GHz-5.725 GHz)

WiFi Reception Sensitivity

1.5 GHz-1:

2.11a 6Mbps:-93dBm, 11a 54Mbps:-76dBm

3.11ac VHT20 MCS0:-92dBm, 11ac VHT20 MCS8:-69dBm

4.11ac VHT40 MCS0:-90dBm, 11ac VHT40 MCS9:-65dBm

5.11ac VHT80 MCS0:-87dBm, 11ac VHT80 MCS9:-62dBm

6.11ax HE20 MCS0:-93dBm,11ax HE20 MCS11:-62dBm

7.11ax HE40 MCS0:-90dBm,11ax HE40 MCS11:-59dBm

8.11ax HE80 MCS0:-87dBm,11ax HE80 MCS11:-56dBm

9.5 GHz-2 (Gaming Band):

10.11a 6Mbps:-96dBm, 11a 54Mbps:-77dBm

11.11ac VHT20 MCS0:-95dBm, 11ac VHT20 MCS11:-64dBm

12.11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS11:-62dBm

13.11ac VHT80 MCS0:-90dBm, 11ac VHT80 MCS11:-59dBm

14.11ac VHT160 MCS0:-84dBm, 11ac VHT160 MCS11:-53dBm

15.11ax HE20 MCS0:-93dBm,11ax HE20 MCS11:-62dBm

16.11ax HE40 MCS0:-90dBm,11ax HE40 MCS11:-59dBm

17.11ax HE80 MCS0:-87dBm,11ax HE80 MCS11:-57dBm

18.11ax HE160 MCS0:-84dBm,11ax HE160 MCS11:-54dBm

2.4 GHz:

11g 6Mbps:-96dBm, 11g 54Mbps:-77dBm

11n HT20 MCS0:-95dBm, 11n HT20 MCS7:-76dBm

11n HT40 MCS0:-93dBm, 11n HT40 MCS7:-73dBm

11ac VHT20 MCS0:-95dBm, 11ac VHT20 MCS8:-73dBm

11ac VHT40 MCS0:-92dBm, 11ac VHT40 MCS9:-68dBm

11ax HE20 MCS0:-95dBm,11ax HE20 MCS11:-64dBm

11ax HE40 MCS0:-95dBm,11ax HE40 MCS11:-62dBm

PHYSICAL
Dimensions (W×D×H)	8.3 × 8.3 × 2.0 in (212 × 212 × 51.8 mm)
Package Contents	Wi-Fi Router Archer GX90 Power Adapter RJ45 Ethernet Cable Quick Installation Guide
