Gigabyte GeForce RTX 5050 WINDFORCE OC 8G – two fans – GV-N5050WF2OC-8GD

Gigabyte RTX 5050 WINDFORCE

FEATURES

• Powered by the NVIDIA Blackwell architecture and DLSS 4
• Powered by GeForce RTX™ 5050
• Integrated with 8GB GDDR6 128bit memory interface
• WINDFORCE cooling system
  • Hawk fan
  • Server-grade Thermal conductive gel
• Reinforced structure

HAWK FAN

The Hawk Fan features a unique blade design inspired by the aerodynamics of an eagle’s wing. This design reduces air resistance and noise levels, resulting in up to a 53.6% increase in air pressure and a 12.5% increase in air volume without compromising acoustics.

SERVER-GRADE THERMAL CONDUCTIVE GEL

To enhance product quality and reliability, we have introduced server-grade thermal conductive gel for cooling critical components such as VRAM and MOSFETs. This highly deformable, non-fluid gel provides optimal contact for uneven surface and effectively resists deformation from transport or long-term use, unlike traditional thermal pads.

Specification

Graphics Processing
GeForce RTX™ 5050

Core Clock
2587 MHz (Reference card : 2572 MHz)

CUDA® Cores
2560

Memory Clock
20 Gbps

Memory Size
8 GB

Memory Type
GDDR6

Memory Bus
128 bit

Card Bus
PCI-E 5.0

Digital max resolution
7680×4320

Multi-view
4

Card size
L=199 W=116 H=40 mm

PCB Form
ATX

DirectX
DirectX 12 API

OpenGL
4.6

Recommended PSU
550W

Power Connectors
8 Pin*1

Output

DisplayPort 2.1b *2 // HDMI 2.1b *2

Accessories
Quick guide
