More about Barcode Scanner X-9201B Wireless

Scanning Capability

Reads all standard 1D barcodes, even from electronic screens.

Sensor & Speed

Japanese linear CCD sensor with a scan rate of up to 500 scans per second.

Wireless Connectivity

Supports Bluetooth 4.0 and virtual Bluetooth mode with a wireless range of up to 30 meters.

Battery

Built-in 2000mAh lithium battery, offering long-lasting performance—up to 24 hours of continuous scanning.

Specification of Barcode Scanner

 Physical Specs

• Dimensions: 167 × 97 × 65 mm
• Weight: Approx. 115g (without cable)
• Material: ABS + PVC + PC
• Color Options: Black or White
• Button Lifespan: >100,000 presses

 Power & Battery

• Battery: Built-in 3.7V 2000mAh lithium battery
• Charging Voltage: DC 5V ±5%
• Charging Time: 4–6 hours
• Working Time: Up to 24 hours (continuous scanning)
• Current Consumption: 114mA (working), 50mA (standby), 205mA (max)

Connectivity

• Wireless Modes: Bluetooth 4.0 & Virtual Bluetooth & Wireless 2.4Ghz
• Wireless Range: Up to 30 meters
• Interfaces: USB cable, Bluetooth

Scanning Performance

• Sensor: Japanese Linear CCD
• Scan Rate: Up to 500 scans/second
• Resolution: 4 mil (0.1 mm)
• Reading Distance: 10 mm – 600 mm
• Motion Tolerance: 100 mm/s
• Supported Barcodes: All standard 1D types (Code128, EAN-13, UPC-A, Code39, etc.)

Processing & Storage

• Processor: 32-bit ARM Cortex-M3
• Memory: 64K (stores ~3500 barcodes in offline mode)

Compatibility & Language

• OS Support: Windows, Android, Linux, macOS, iOS
• Languages: 20+ keyboard layouts including English, French, German, Japanese, Russian, etc.

 Environmental & Durability

• Operating Temp: 0°C to 50°C
• Storage Temp: -20°C to 70°C
• Humidity: 20%–95% (non-condensing)
• Drop Resistance: 1.5 meters
• IP Rating: IP54 (dust and splash resistant)
• ESD Protection: 15kV air discharge
