tplink AC1200 Extender RE305
tplink AC1200 Wi-Fi Range Extender [RE305]
Overview
Brings Wi-Fi dead zone to life with strong Wi-Fi expansion at combined speed of up to 1.2Gbps
Operates over both the 2.4GHz band(300Mbps) and 5GHz band(867Mbps) for more stable wireless
Intelligent signal light helps to find the best location for optimal Wi-Fi coverage by showing the signal strength
Works with any Wi-Fi router or wireless access point tplink AC1200 Extender RE305
Easily Expand Your Wi-Fi Coverage
Tired of Wi-Fi dead zones in your home? The RE305 Range Extender connects to your Wi-Fi router wirelessly, strengthening and expanding its signal into areas it can’t reach on its own.
The RE305 lets you keep more devices connected at the same time with its 2.4GHz 300Mbps and 5GHz 867Mbps dual bands. Use the 2.4GHz band to send email and browse the web,.
Perfect Location at a Glimpse
An Intelligent Signal light helps you quickly find the best location to install the RE305.
Built-in Access Point Mode
RE305 is more than a wireless range extender. Simply plug the Ethernet cable into its Ethernet port to easily turn your wired internet connection into a dual band wireless access point.
Specification
HARDWARE FEATURES
Plug Type
EU, UK, US
Standards and Protocols
IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b
Interface
1 x 10/100M Ethernet Port (RJ45)
Button
WPS Button, Reset Button
Power Consumption
7.3W(max power consumption)
Dimensions ( W x D x H )
3.1 x 3.0 x 3.0 in. (80 x 78 x 77mm)
Antenna
2 x external
WIRELESS FEATURES
Frequency
2.4GHz & 5GHz(11ac)
Signal Rate
5GHz:Up to 867Mbps
2.4GHz:Up to 300Mpbs
Reception Sensitivity
5GHz:
11a 6Mbps:-91dBm@10% PER
11a 54Mbps: -74dBm@10% PER
11ac HT20 mcs8: -68dBm@10% PER
11ac HT40 mcs9: -63dBm@10% PER
11ac HT80 mcs9: -59dBm@10% PER
2.4GHz
11g 54M: -79dBm@10% PER
11n HT20 mcs7: -77dBm@10% PER
11n HT40 mcs7: -74dBm@10% PER
Wireless Modes
Range Extender/Access Point
Wireless Statistic
Concurrent Mode boost both 2.4G/5G Wi-Fi band
Wireless Functions
Wireless Statistic
Concurrent Mode boost both 2.4G/5G Wi-Fi band
Access Control
LED Control
Domain Login Function
tplink AC1200 Extender RE305
Wireless Security
64/128-bit WEP
WPA-PSK / WPA2-PSK
Transmission Power
