Intel® Core™ i5-9600K Processor 9M Cache, up to 4.60 GHz (LGA1151)

Intel® Core™ i5-9600K Unlocked (LGA1151) CPU

 9MB Cache , up to 4.60 GHz , 6 Cores / 6 Threads , TDP: 95W , Intel® UHD Graphics 630 , FCLGA1151 , Intel® Trubo Boost Technology 2.0 , Intel® Optane™ Memory Ready.

Code Name: Coffee Lake


Product Code: BX80684I59600K


9th Gen Intel Core i5-9600K Desktop processor with Intel Turbo Boost Technology 2.0 offers powerful performance for GAMING , Creating and productivity.

Note: Thermal soultion NOT included in the box.

Only compatible with 300 series chipset based motherboards.

Tech. Specs. :

Essentials

Product Collection9th Generation Intel® Core™ i5 Processors
Code NameProducts formerly Coffee Lake
Vertical SegmentDesktop
Processor Numberi5-9600K
StatusLaunched
Launch DateQ4’18
Lithography14 nm
Use ConditionsPC/Client/Tablet

Performance

# of Cores6
# of Threads6
Processor Base Frequency3.70 GHz
Max Turbo Frequency4.60 GHz
Cache9 MB SmartCache
Bus Speed8 GT/s DMI3
TDP95 W

Supplemental Information

Embedded Options AvailableNo
DatasheetView now

Memory Specifications

Max Memory Size (dependent on memory type)64 GB
Memory TypesDDR4-2666
Max # of Memory Channels2
Max Memory Bandwidth41.6 GB/s
ECC Memory Supported ‡No

Processor Graphics

Processor Graphics ‡Intel® UHD Graphics 630
Graphics Base Frequency350 MHz
Graphics Max Dynamic Frequency1.15 GHz
Graphics Video Max Memory64 GB
4K SupportYes, at 60Hz
Max Resolution (HDMI 1.4)‡4096×2304@24Hz
Max Resolution (DP)‡4096×2304@60Hz
Max Resolution (eDP – Integrated Flat Panel)‡4096×2304@60Hz
DirectX* Support12
OpenGL* Support4.5
Intel® Quick Sync VideoYes
Intel® InTru™ 3D TechnologyYes
Intel® Clear Video HD TechnologyYes
Intel® Clear Video TechnologyYes
# of Displays Supported ‡3
Device ID0x3E98

Expansion Options

Scalability1S Only
PCI Express Revision3.0
PCI Express Configurations ‡Up to 1×16, 2×8, 1×8+2×4
Max # of PCI Express Lanes16

Package Specifications

Sockets SupportedFCLGA1151
Max CPU Configuration1
Thermal Solution SpecificationPCG 2015D (130W)
TJUNCTION100°C
Package Size37.5mm x 37.5mm

Advanced Technologies

Intel® Optane™ Memory Supported ‡Yes
Intel® Turbo Boost Technology ‡2.0
Intel® vPro™ Platform Eligibility ‡Yes
Intel® Hyper-Threading Technology ‡No

2-Years Warranty

&
