HIKVISION 21.5″ FHD Monitor

HIKVISION 21.5″ FHD Monitor (DS-D5022FN00)

• Display

• Screen Size21.5 inch
• Active Display Area478.656 mm × 260.280 mm
• Resolution1920 × 1080@60 Hz
• BacklightE-LED
• Pixel Pitch0.0831 mm (H) × 0.241 mm (V)
• Brightness250 cd/m²
• Viewing Angle178° (H) / 178° (V)
• Color Depth8 bit
• Contrast Ratio3000 : 1
• Response Time6.5 ms
• Refresh RateMax. 75Hz , Typ. 60 Hz
• HazeHaze 25%, 3H
• Reliability7 × 16 H
• Color Gamut72% NTSC

• Interface

• Video & Audio InputHDMI 1.4 × 1, VGA × 1
• Video & Audio OutputNone
• Data Transmission InterfaceNone
• Control InterfaceNone

• Power

• Power SupplyDC 12V, 2.0A
• Power Consumption≤ 24 W
• Standby Consumption≤ 0.5 W

• General

• Casing MaterialPlastic
• VESA75 mm × 75 mm (4 – M4 × 6 mm)
• Bezel Width6.85 mm (top/left/right), 21.55 mm (bottom)
• Product Dimensions (W × H × D)492.4mm（W）× 390.1mm（H）× 200.2mm（D）mm
• Package Dimensions (W × H × D)599mm（W）x 393mm（H）x 109 mm（D）
• Net Weight2.08 ± 0.5 kg
• Gross Weight3.4 ± 0.5 kg
• Packing ListMonitor × 1, Base component × 1, Power adapter (12 V, 2.0 A) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1
• RemarksIf the appearance and parameters in this specification vary from the actual product, the later prevails. You can also consult local sale staff.

• Working Environment

• Working Temperature0℃ to 40 ℃ (32 ℉ to 104 ℉)
• Working Humidity10% to 90% RH (Non-Condensing)
• Storage Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
• Storage Humidity0% to 90% RH
