Eaton 5E 1100i USB UPS Battery Backup (5E 1100iUSB)

Eaton 5E 1100i USB UPS Battery Backup
(5E 1100iUSB)
Protects Data and Electronics
(AVR) Automatic Voltage Regulation

x  outlets with battey backup
1x USB power management port
2x Modem internet line protection
2x  Loop Power Cable are icluded

Specifications :

CAPACITY = 850 VA / 660 W
INPUT = 170V-280V
BATTERY = (2) 12V 7Ah
USB PORT = YES
RECHARGING TIME = 6 hours to 90% after complete discharge
SURGE SUPPRESSION = YES
COMMUNICATION = YES
BACKUP TIME = 30 min.
WEIGHT = 9.3 Kg

Eaton 5E UPS

Replacement of Eaton Nova & NV UPS

The Eaton 5E is an essential line interactive UPS that provides cost effective and reliable power protection against power outages and bad power quality. Thanks to its small size the 5E can be installed easily either in a business environment or at home

Eaton 5E UPS – Features

Work through under & overvoltage without wasting battery thanks to Automatic Voltage Regulation (AVR)
Rely on batteries anytime : 5E batteries are permanently recharged (even when off) and UPS can start without mains (Cold-start)
Avoid back door damages coming through phone lines : 5E USB models are equipped with data line surge protection (Internet/Tel/Fax)
Plug easily any equipment to the UPS (PC, HD TV, internet gateway,…) thanks to IEC and Schuko outlets (on DIN models)
Install 5E anywhere thanks to its small size
Easily manage your UPS from your PC
Ensure peace of mind thanks to a 1-year warranty (automatically included)

Eaton 5E UPS – Technical Specifications

Product Snapshot

Power Rating
500-2000 VA

Voltage
230 V

Frequency
50/60 Hz

Topology
Line-interactive

Configuration
Tower

UPS Models

Part Number
Power Rating
Input Plug
Outlets

(VA/Watts)

Eaton 5E IEC

5E500i
500 / 300
C14
(4) C13

5E650i
650 / 360
C14
(4) C13

5E650iUSB
650 / 360
C14
(4) C13

5E850iUSB
850 / 480
C14
(4) C13

5E1100iUSB
1100 / 660
C14
(6) C13

5E1500iUSB
1500 / 900
C14
(6) C13

5E2000iUSB
2000 / 1200
C14
(6) C13

Eaton 5E DIN

5E650iDIN
650 / 360
C14
(2) C13, (1) Schuko

5E650iUSBDIN
650 / 360
C14
(2) C13, (1) Schuko

5E850iUSBDIN
850 / 480
C14
(2) C13, (1) Schuko

See All Eaton 5E UPS Documentation

See all Eaton 5E models

5E850iUSB

Eaton 5E 850VA USB 230V

General

Topology
Line Interactive with Automatic Voltage Regulation

Configuration
Tower

Style Number
5E850iUSB

Part Number
5E850iUSB

Rating (VA/Watts)
850VA/480W

Dimensions (H x W x D, mm)
288 x 148 x 100

Weight (kg)
5.16

Warranty
2 years

Electrical Input

Connection

(1) IEC-320-C14

Input Voltage Range
170-280V

Nominal Voltage
230 V

Operating Frequency
50/60Hz

Electrical Output

Nominal Voltage
230V

Outlets

(4) IEC-320-C13

Battery

Runtime
(Minutes)

50

100

150

200

250

300

0

5

10

15

20

25

30

35

40

45

50

55

Standard Runtime

Load (Watts)

Battery runtimes are approximate and may vary with equipment, configuration, battery age, temperature, etc.

Load (Watts):
Standard Runtime:

Battery Management
Permanent battery recharge, cold start

Communications

Communication Ports
1 USB port

Power Management Software
Eaton UPS Companion software

Environmental & Standards

Audible Noise
