Machine Type

Colour Laser All-In-One

Available Functions

Print, Copy, Scan

Print Speed

• Single sided: Up to 33 ppm (A4), Up to 60 ppm (A5-Landscape)

• Double sided: Up to 29.5 ipm (A4)

Printing Method

Colour laser beam printing

Print Resolution

Up to 1200 x 1200 dpi

Warm-up Time

Approx. 14 seconds or less from power on

First-Print-Out Time

• Colour: Approx. 8.38 seconds or less

• Mono: Approx. 8.16 seconds or less

Printer Languages & Fonts

• Languages: UFRII, PCL 5c, PCL6

• Fonts: 45 PCL fonts

Print Margins

• Standard: 5 mm (Top, Bottom, Left, Right)

• Envelope: 10 mm (Top, Bottom, Left, Right)

Toner Saver Mode

Yes

Advanced Printing Features

Encrypted Secure Print, Secure Print, Print from USB memory key (JPEG/TIFF/PDF), Print from Cloud (Dropbox, Google Drive, OneDrive – PDF/JPEG), Microsoft Universal Print support

• Mobile/App: AirPrint (iOS), Canon PRINT app, Mopria certified (Android), Canon Print Service Plug-in, IPP Everywhere

Copy Speed

• Single sided (A4): Up to 33 ppm

• Double sided (A4): Up to 29 ipm

First-Copy-Out Time

• ADF (A4): Colour ~8.8s or less / Mono ~7.6s or less

• Platen (A4): Colour ~9.4s or less / Mono ~8.3s or less

Copy Resolution & Modes

• Resolution: Up to 600 x 600 dpi

• Modes: Text/Photo/Map (Default), Text/Photo/Map (quality), Printed Image, Text

Double Sided Copying

2-sided to 2-sided (Automatic)

Multiple Copies & Zoom

• Multiple Copies: Up to 999 copies

• Reduction / Enlargement: 25–400% in 1% increments

Other Copy Features

Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Two-sided Original, Sort, N on 1, Sharpness, Erase Frame, Copy ID Card, Copy Passport, Color Mode, Reserved copy

Scan Specifications

• Type: Colour

• Optical Resolution: Up to 600 x 600 dpi

• Enhanced Resolution: Up to 9600 x 9600 dpi

• Speed (300x300dpi): Single sided (Mono 50ipm / Colour 40ipm), Double sided (Mono 100ipm / Colour 80ipm)

• Speed (300x600dpi): Single sided (Mono 40ipm / Colour 20ipm), Double sided (Mono 80ipm / Colour 40ipm)

• Depth & Greyscales: 24-bit input/output, 256 levels

• Compatibility: TWAIN, WIA, ICA

• Max Scan Width: 216 mm

Scan Destinations & Formats

• Destinations: E-mail, PC, USB Memory Key, FTP, Cloud

• Supported Formats: TIFF, JPEG, PDF, Compact PDF, Searchable PDF, PDF/A-1b, PNG (Cloud only)

Media Handling & Scanner Type

• Scanner Type: Platen, 2-sided ADF (single pass)

• Paper Input (Standard): 250-sheet cassette, 50-sheet multi-purpose tray, 50-sheet ADF

• Paper Input (Option): 550-sheet cassette

• Max Paper Input Capacity: 850 sheets

• Paper Output: 150 sheets

Media Types

Plain paper, Recycled paper, Heavy Paper, Thin paper, Colour paper, Coated paper, Pre-punched, Label, Post card, Envelope

Media Sizes

• Cassette (Standard): A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Envelopes (COM10, DL, C5, Monarch); Custom (Min. 98×148 mm to Max. 216×356 mm)

• Multi-purpose Tray: A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Indexcard, Envelopes (COM10, DL, C5, Monarch); Custom (Min. 76×127 mm to Max. 216×356 mm)

• Cassette (Optional): A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card; Custom (Min. 100×148 mm to Max. 216×356 mm)

• ADF: A4, A5, A6, B5, Legal, Letter, Statement; Custom (Min. 48×85 mm to Max. 216×355.6 mm)

Media Weights & Duplex Printing

• Cassettes: 60 to 163 g/m² (Up to 200 g/m² with Coated paper)

• Multi-purpose Tray: 60 to 176 g/m² (Up to 200 g/m² with Coated paper)

• ADF: 50 to 105 g/m²

• Auto Duplex Sizes: A4, A5, B5, Legal, Letter, Executive, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K; Custom (Min. 148×148 mm to Max. 216×356 mm, 60–200 g/m²)

Interface & Connectivity

USB 2.0 Hi-Speed, 10BASE-T/100BASE-TX/1000Base-T Ethernet, Wireless 802.11b/g/n, Wireless Direct Connection

OS Compatibility

• Windows 11 / 10 / Server 2025 / 2022 / 2019 / 2016

• Mac OS X version 10.15 & up

• Linux

Network Protocols & Security

• Print: TCP/IP (LPD/Port9100/IPP/IPPS/WSD)

• Scan Push: File (FTP, SMB3.1.1), E-mail/I-Fax (SMTP send, POP3 receive); Scan Pull: TCP/IP

• Management: SNMPv1, SNMPv3 (IPv4, IPv6)

• Security: TLS1.3, IPSec, IP address filtering, IEEE802.1X, SNMPv3, SSL (HTTPS, IPPS)

• Wireless Security: WPA/WPA2/WPA3 (PSK/EAP), Access Point Mode (WPA2-PSK, WPA3-SAE)

Software & Management

MF Scan Utility, Remote User Interface (RUI), Department ID Management, Toner Status Tool, iW Enterprise Management Console, SIEM integration support, eMaintenance, Application Library

General Hardware Specs

• Recommended Monthly Volume: 750 – 4,000 pages per month

• Duty Cycle: Max. 50,000 pages per month

• Processor Speed: 1200 MHz

• Memory: 1GB

• Storage: 4GB

• Control Panel: 12.7 cm (5-inch) LCD Colour Touch Screen

Dimensions & Weight

• Dimensions (W x D x H): 425 mm x 461 mm x 430 mm

• Installation Space (W x D x H): 625 mm x 1,117 mm x 990 mm

• Weight: Approx. 23.30 kg

Operating Requirements

• Temperature: 10 to 30ºC (50 to 86ºF)

• Humidity: 20 to 80% RH (no condensation)

• Power Source: 220-240V (±10%) 50/60Hz (±2Hz)

Power Consumption

• Maximum: Approx. 1,380 W

• Active Printing: Approx. 700 W

• Standby: Approx. 24.0 W

• Sleep Mode: Approx. 1.0 W

• Typical Electricity Consumption (TEC): 0.30 kWh/week (230V)

Noise Levels

• Sound Pressure: Active (51dB Simplex/Duplex BW, 50dB CL), Standby (29 dB)

• Sound Power: Active (65dB or less), Standby (41dB or less)

Consumables (Toners)

• Cartridge 069 Black (2,100 pages) / Cartridge 069H Black (7,600 pages)

• Cartridge 069 Cyan (1,900 pages) / Cartridge 069H Cyan (5,500 pages)

• Cartridge 069 Magenta (1,900 pages) / Cartridge 069H Magenta (5,500 pages)

• Cartridge 069 Yellow (1,900 pages) / Cartridge 069H Yellow (5,500 pages)
